Duh, It’s DER!

What’s in a name? Sometimes, it’s everything. DER, or Distributed Energy Resources, is the name given to a collection of energy solutions defined by small scale renewable energy sources combined with advanced information and control technologies that can be aggregated to provide reliable energy necessary to meet regular demand. Examples include: renewable generation, energy storage, energy efficiency, demand response, electric vehicles and any combination thereof.

Today DER means rooftop solar, with a little bit of Electrical Vehicle (EV) charging sprinkled here and there. Both rooftop solar and EV charging occur behind-the-meter, on private residential or commercial property, beyond the influence of the Investor-Owned Utility (IOU). In fact much of the rooftop solar going in today is provided by third party leases from companies like Solar City and SunPower, who are in direct competition with IOUs. Competition for rooftop solar DER is fierce, making it challenging for IOUs to play a significant role, especially when hamstrung by existing business models involving fixed rates of return. The only viable way for IOUs to leverage this class of third party (and customer-owned for that matter) rooftop DER is through program incentives. With the right incentives, participating customers can be persuaded to source energy from rooftop arrays or sync energy into EV batteries at meaningful times to the IOU just like they do with energy efficiency programs targeting thermostats, but the impact is small and indirect and may conflict with the financial benefits of these third party systems.

What will DER mean tomorrow? California may be first to decide. California has mandated (AB-327/Rulemaking14-08-013) that their IOUs deliver Distribution Resource Plans (DRP) by July 1, 2015 that include high levels of DER. In addition SB-43 , also known as “Community Solar”, mandates solar for everyone, not just those folks with sufficient rooftop real estate and credit scores. Both of these aggressive California mandates share a common problem – siting.

If you believe the Distribution System Operator (DSO) model is where we are headed, then the answer to the siting problem for DER and Community Solar may be along the low-voltage secondary distribution system, before-the-meter, on existing infrastructure and easements so that DSOs can own and operate these resources. Imagine solar generation added to existing outdoor light poles and then at the head-end of the lighting circuit, energy storage and power regulation are sited, sharing a common easement, interconnection point and information/control solution. Voilà, Local-Area DER!

Local-Area DER

Such a Local-Area DER solution has many benefits including:

  • Small-scale capacity with power regulation
    • Solar generation plus battery storage
    • Dispatch-able and load shifting
    • Resolve existing power quality issues w/regulators
    • New high-quality capacity w/smart microinverters
  • Located “before-the-meter”
    • DSO owned, operated & controlled
    • Meets incremental demand with co-located supply, reducing transmission losses
    • Adds value to distribution “wires”
    • Low-voltage: 120/240/480V, single or three-phase
  • Utilizes existing infrastructure
    • Quick, easy and economical to implement
    • Reduce or eliminate land use and permitting issues
    • Build up balance and reliability across interconnections from the edge
  • Deployable in lock-step with behind-the-meter grid issues
    • Similar sizing to “behind-the-meter” DER
    • Co-located along the same “wires” with issues
    • Economically scaled as grid issues scale

In addition to these benefits, siting Local-Area DER along existing roadside infrastructure where low-voltage distribution “wires” reside is democratic. Everyone lives near roadways, whether renting an apartment or residing in a structure incapable of hosting a rooftop solar installation, so Local-Area DER delivers on the Community Solar promise of environmental justice too.

Local vs Wide-Area DER

Wide-Area DER, sited further up the distribution system hierarchy at the sub-transmission or primary distribution level, does not deliver the same degree of benefit. Real estate remains a challenge to procure. Even though the amount of land required is less than a full-scale gigawatt solar farm, acquisition, permitting, land use, environmental and legal issues still abound. Plus the energy must traverse the distribution system to get where it is needed most, which may necessitate some of the very same switch and wire upgrades DER is intended to avoid.

There are scale matching issues as you move up the hierarchy as well. The number of circuits that can be addressed with a single solution increases as you move up the hierarchy, but the ability to target some circuits out at the edge but not others requires additional investments in power routing solutions. System sizing up the distribution system hierarchy can also be challenging. How much generation, storage and power regulation is needed today across all the rapidly evolving circuits, and tomorrow, and the day after that? IOUs are very skilled at modeling circuits and predicting load, so this would not seem like a concern on the surface. However, these well-oiled processes cannot match the pace of unpredictable change unfolding behind the meter.

Instead, a single circuit with occasional bi-direction power flow, power factor and harmonic issues can be targeted with a single circuit-sized Local-Area DER solution leveraging land and infrastructure whose cost is already sunk. Comparable sizing combined with co-location before the meter along the same circuit resolves these issues quickly and economically and helps the DSOs maintain control over their system while meeting their ever present reliability expectations.

So, what’s in a name? If the name is DER and it is preceded by the adjective Local-Area, it could be everything.

Franken’home

I love architecture. I also love technology, so blending the two is a fantasy, or so I thought. Turns out my day job in highly distributed renewable energy forces me to rethink all of the systems in a home in the context of the latest efficiency, generation and storage technologies. Doing so is hard and turns my fantasy into some kind of Franken’home, stitched together from bits and pieces across several industries. Here’s what I mean.

First and foremost, my dream home is perched on a low-bank waterfront parcel on the Puget Sound near Seattle, Washington. If you have never meandered a salty sound beach, dodging star fish and geoducks and inhaling that pungent kelp-filled fragrance, you are missing out. But I digress…

Of course my dream home is efficient, adhering to the latest passive solar home design principles including a highly performant building envelope with carefully managed airflow, orientation that maximizes seasonal use of sunlight and a suitably sized thermal mass integrated into the home design as concrete flooring and walls. Combined these passive solar principles ensure my dream home barely sips energy.

Even so, today’s modern life filled with electronics comes at a price; the auxiliary energy load is high. Multiple computers, media equipment, appliances, electric car chargers and the like all require energy. Plus Seattle is not exactly bathed in sunshine all year long like the Southwest. To meet this load above and beyond the passive solar design, my dream home has rooftop solar, perhaps an 18 kilowatt installation. Leveraging the beachfront location, a 2 kilowatt micro-wind turbine takes advantage of the prevalent winds and helps to offset the load as well. Solar and wind variability necessitates storage, so my dream home also has a 30 kilowatt-hour, lithium-iron-phosphate battery storage system to smooth out this variability and accommodate the long winter nights at 48 degrees North latitude. Even with all this onsite generation and storage capacity, however, I still believe there will be long-term value in remaining connected to the electricity grid so my dream home includes a net meter with a connection to and relationship with my local electric utility.

USB Ports

Now that energy is covered, what’s next? Lighting. All lighting, indoor as well as outdoor and landscape lighting, leverages dimmable LED technology. Moreover, dedicated DC-only lighting circuits are built into my dream home and powered by the DC battery system. Doing so eliminates the incredible redundancy of converting natively DC lighting to AC every time it connects to power. The battery system is charged by solar and wind, which of course are both variable DC, and then on rare occasion by the AC connection to the electricity grid when renewable fuel falls short of demand or becomes more economical. In turn, the battery system serves to smooth out this variability, delivering consistent DC voltage for all lighting. This consistent DC voltage also gets used throughout my dream home to power DC accessories via Universal Serial Bus (USB) interfaces integrated everywhere. Imagine how convenient your kitchen island and counters, and even bathroom counters, become with traditional AC power receptacles plus USB ports for charging the myriad electronic devices now standardized on USB cables for power.

Cistern

While the greater Seattle area ranks low for solar irradiance, rainfall is abundant, so rain water is carefully managed. All water on the structure and surrounding flat-scapes is collected, filtered and stored in an underground cistern, along with gray water generated inside the home from lavatories, tubs, showers, etc. Gray water in the cistern is then recycled for use in flushing toilets and for landscape watering.

Radiant Heat

On to heating. Have you ever experienced in-floor radiant heat, also known as hydronic radiant floors? The experience warms the soul (or sole anyway.) Because your feet are warm, and heat rises, the experience is very satisfying. It can also be very efficient, especially when embedded in concrete floors serving as thermal mass and mated to the latest solar water heating technology. Sure, a pump is required to recirculate the high energy-density fluid through the hydronic tubing, but very little electricity is required to actually heat the fluid. Only when the concrete flooring cools below the comfort level does in-floor radiant heat even need to kick in, and then only when there’s insufficient sunshine does the fluid need to be heated with an auxiliary electric heat exchanger. So my dream home includes in-floor radiant heating with a solar heat exchanger and electric backup.

Daikin

What about cooling? The greater Seattle area is not known for its long stretches of 100+ degree days in the summer, but given the location of my dream home on the Puget Sound, taking in the view is paramount. View means glass, and glass means cooling load, especially when facing south or west. In-floor or in-ceiling radiant cooling is an elegant solution for all the same reasons in-floor radiant heating is. Unfortunately, radiant cooling is subject to condensation issues when relative humidity is high, which is the case in Seattle, so this solution will not work. Instead, careful attention is paid to passive solar design details like glass properties and thermal conduction between the poured concrete floor and the cool earth below, which dramatically reduces the cooling load overall. Then an efficient air-to-air heat exchanger like the one from Daikin is used for spot cooling where and when necessary.

Nest

My Franken’home is lying on the operating table all stitched together, an amalgamation of disparate yet highly efficient systems. It is not, however, alive. To make my dream home live, it’s not lightening I need but a control system, and this is the biggest gap in today’s available technologies. Nest, recently purchased by Google for a whopping $3.2 billion, helps show the way with its clever activity-based learning and optimization. My dream home takes this idea and extends it throughout all systems in order to give it life. Sensors abound. Each room or area in my dream home has its own hydronic radiant floor zone, lighting zone, window covering or shading zone, temperature sensors at ground level, torso level and ceiling level, occupancy sensors and lumen sensors for brightness. These sensors provide the real time feedback loop necessary to optimize the various systems over time. Plus each room or area has a manual control for temperature, lighting and shading. Then like Nest on steroids, over the course of a year’s worth of seasons, my dream home’s control system learns the relationships between season, time of day and activity – reinforced by manual adjustments to systems – and derives common default behaviors with the twin goals of hands-free comfort and energy efficiency most of the time. Overrides will occur all the time, and will remain easy, but with more and more time the activity trends will emerge that enable the system to be comfortable and energy efficient, automatically.

Energy efficiency in the context of occupant comfort has more to do with load management. The other dimension of efficiency in my dream home with onsite energy generation and storage plus a connection to the electricity grid involves economics. When should onsite energy generation be used directly by house loads, stored in the battery system or inverted through the utility’s meter onto the grid? The answer lies in the relative costs and benefits of the various options based on the time of use. Utility energy prices over time are one key input. For example, if energy is being generated when the utility will pay a premium, then this energy is inverted onto the grid while the house runs off the battery system. However, if historically the next day has a particularly high demand for lighting and USB device usage and there is insufficient time to fully top off the battery system overnight, then some of the renewable energy generation is used to charge the battery system instead.

Meter and CT

Like the temperature, lumen and occupancy sensors used to optimize the energy loads of comfort systems, optimizing energy economics needs sensors too. These sensors are called meters, with current transformers (CT), and they measure energy, power, current, voltage and a host of more esoteric power parameters. My dream home includes granular energy monitoring. Each of the comfort systems – heating, cooling, lighting and shading – has its own meter and CT for individual monitoring. The heating system utilizes a pump and backup electric heat exchanger so each of these sub-systems is individually monitored with its own meter and CT. All major appliances are individually monitored too – refrigerator, oven, induction cooktop, microwave, dishwasher, clothes washer and dryer, media equipment and EV car charger. All DC USB accessory circuits are monitored together with a single meter and CT, as are the conventional AC power receptacle circuits, so individual accessories won’t be identifiable but accessory energy usage as a whole will be. Energy generation systems are also individually monitored. Together, all this monitoring information gets used to learn and optimize the economic performance of my dream home over time.

This level of whole-house system integration centered on simplicity for the home owner does not exist today, which seems shocking. It is such an obvious problem and all the bits and pieces exist separately, yet the path to integration redemption is littered with carcasses of startups and mature multinationals that have tried and failed. The market for whole-house system integration and automation is fragmented, as are standards. Plus the sales channels are wide and varied, a testament to the many ways such systems come to be in a house. This is a tough business challenge, but one that I hope will come along for the ride as energy efficiency, generation and storage innovations needing integration and automation flourish in the coming years.

One additional gap in today’s technology keeps my stitched-together Franken’home from getting off the operating table and really living: fire. I love fire. The ambiance and warmth it provides as an aesthetic design feature inside and outside is difficult to beat. More importantly, I love to grill. My dream home has an outdoor kitchen worthy of a Food Network television show, though it is covered. We are talking the Seattle area after all. Yet fire needs fuel, and fire fuel is neither renewable nor green. It’s a conundrum. On second thought, it’s not so much a technology gap as a personal problem. I am too unevolved to live without fire, but may be exactly unevolved enough to work for Geico Insurance.

The Breakup Letter

T-Mobile is running a clever little ad campaign urging mobile phone customers to send their controlling carriers a breakup letter. It’s all about early termination fees, which keep customers tethered to their current carrier for the duration of their contract. These fees help carriers recoup the cost of subsidizing the mobile phone hardware – for example, a $499 smartphone can be had for free with a 2-year contract. If the customer wishes to leave before the carrier can earn out their $499 plus a tidy margin, the carrier recovers the unpaid balance via early termination fees.

I wonder whether energy customers would like to send their controlling utility companies a breakup letter too. Residential customers in Hawaii and commercial customers paying demand charges in California probably like the idea quite well. Their electric utilities, asleep at the wheel while innovations in energy efficiency, generation and storage reduce demand for their product, have been levying early termination fees of a different sort. Imagine hundreds of millions of dollars tied up in a centralized, coal-fired power plant. Ten years ago the plan was to earn out this whopping upfront investment – plus a reasonable return – over the next 30 years from $$/kWh paid by a captive audience of energy customers. Trouble is, the audience is no longer captive. Energy customers are being more efficient. They are buying or leasing rooftop solar and in some places, going completely off grid. As demand for the utility’s product wanes, meeting this 30-year obligation requires these electric utilities to increase their energy prices in order to keep the shortfall at bay. Increasing energy prices, in turn, further decreases demand and perpetuates the cycle. Energy customers unwilling or unable to employ efficiency, generation or storage innovations are left behind to pay these higher energy prices – akin to early termination fees.

Dramatically, the Rocky Mountain Institute just published data crisply answering the question of when it will become economically viable to defect from the energy grid entirely using solar photovoltaic (PV) panels plus lithium ion battery technology. The answer is an unequivocal “now” in places like Hawaii and within the next 10 years more broadly. More and more utility customers will be terminating early, well ahead of when the electric utility will recoup its earlier investments in centralized energy generation.

BroadbandTrends

As a result, customers are breaking up with their wireless carriers and their electric utilities with more breakups on the way. How do you connect to the Internet at home – digital subscriber line (DSL), cable modem, fiber, wireless, satellite, broadband over powerline (BPL)? According to the Organization for Economic Cooperation and Development (OECD) nearly 70% of all U.S. households have broadband connectivity and the mix of technologies used lays out like this:

BroadbandTable

Penetration of broadband internet access has fundamentally shifted the way media content gets consumed. Most of Gen Y – raised on the Internet – consumes their media content via the web. Armed with their Netflix, Hulu Plus and other Internet-based content subscriptions and the control they provide over what, when and where, Gen Y is shunning traditional television content from the Comcasts and DirectTVs of the world. The only gap in this strategy is live sports content. Often this gap gets closed at bars where the social dynamic of enjoying live sports with friends and food service trumps the convenience of home. Plus, more and more live sporting events can be watched in real time on the Internet via applications like ESPN’s WatchESPN family of device-specific, content-streaming applications for homebodies.

NewsPlatform

Broadband equals streaming, and broader band is better. Innovations yielding faster and faster connection speeds are driving the penetration of fiber throughout major metropolitan areas. Fiber is even winning in rural Greenfield developments that put the “ease” in easement, helping to keep the cost per foot of delivering fiber lower than fiber in urban areas rife with right-of-way issues. Before long, fiber companies will own the connection to the home, like electrical utilities, and yet this connection will be under siege soon as well.

NextGenNetwork

Ever wonder why there are two different wireless networks; why your smartphone shows bars of connectivity to your cellular network while also providing Wi-Fi access to your local home, hotspot or work network? By any chance do you have Voice Over Internet Protocol (VOIP) phones at the office, or even at home via providers like Vonage? A massive shift is afoot, fueled by innovation. Convergence is coming. With the rollout of fourth-generation / long term evolution (4G/LTE) technologies in the cellular networking world comes the acceptance of data, not voice, as the dominant packet being marshalled around. Data means packet switching using the Internet Protocol (IP). Voice is not left out entirely; it too can obviously be marshalled around using IP, so all networks are converging on a single, flat, IP-based technology. Speeds are increasing as well. A third-generation carrier network (3G) can deliver speeds of 1.5 to 3 megabits per second (Mbps) while a 4G/LTE network can deliver 10 to 20 Mbps, today. These speeds are already as good as or better than DSL. Plus the theoretical limits for 4G/LTE approach 100 Mbps down and 50 Mbps up, landing in the realm of fiber solutions. Work is already beginning on the fifth-generation cellular network (5G), with the goal of achieving a flat, all IP-based network and theoretical speeds in the 1 gigabit per second (Gbps) range.

Prognostications

Another breakup letter is in the works. This letter severs ties with Internet Service Providers (ISP) providing underground connectivity (i.e., DSL, cable, fiber) and, ironically, puts mobile carriers front and center once more, but not necessarily the same mobile carriers we know and love today. Coming full circle back to mobile telecommunications purveyors is not the most interesting realization, however. Imagine a world where you do not need to be tied to an electric utility for power or an ISP for connectivity. No ties mean freedom. Sure, you could plop your super energy efficient house with Gbps connectivity anywhere there is sufficient sunshine, wind or both, and a wireless broadband access point. But that is the least interesting ramification, enmeshed as it is in the larger socioeconomic ebbs and flows of urban versus rural renewal. Even more mind-bending are the truly mobile notions. All-electric vehicles covered in flexible solar collecting skins and sporting Gbps connectivity would rarely need to dock, would provide passengers and surrounding vicinity full fidelity access to the Internet, could participate in a bevy of two-way, data-intensive telemetry services and be commonplace. Mobile telemedicine clinics would deliver Western-style medical services to remote, impoverished areas of the world, economically. Beach umbrellas made from foldable solar-collecting fabric, a handle filled with batteries, a Wi-Fi hotspot and a 120V AC receptacle would dot sandy shores everywhere.

As the inspirational music fades, keep the breakup letter in mind. If you are not penning a letter to Verizon Wireless or Duke Energy or Comcast you may find yourself paying too much and labeled a Luddite. After all, innovation changes everything.

Ocean or Archipelago

DeLoreans are rare, especially ones with the flux capacitor option. But if we happened on a pristine example, set the date to 2044 and mashed the pedal, what would we see upon our arrival? Would the energy landscape resemble an ocean where energy consumers and producers are in constant contact, fluidly exchanging energy to capitalize on small differences in price, or would it resemble an archipelago where everyone produces their own energy locally like an island? And what’s so special about 2044?

Bell System

Well, it has been 30 years since the consent decree broke up the Bell Operating Companies that had previously provided local telephone service over copper land-lines in the United States. At the end of 2012, fully half of American households had no land-line telephone service whatsoever, relying 100% on wireless carriers for their real time interpersonal communications. That is a remarkable transformation by any measure, and verifies 30 years as plenty of time for a sweeping sea change. Plus, 30 years is well within the capability of a standard DeLorean flux capacitor.

So ocean or archipelago; the answer may be tied up in how social obligation colors this 30-year sea change. Before diving into the how and the why, though, it’s worth spending a few words on the what.

Ocean

Ocean

What is an energy ocean? Arriving at an energy ocean requires dramatic change to be sure, but most of the fundamental pieces of today’s energy ecosystem remain. Transmission exists. Its role involves bi-directional interstate energy delivery with service offerings delineated by capacity and quality. A consumer of transmission services buys, say, two terawatts of peak transmission capacity per month with five “9”s of reliability at a much higher price than if they were buying 150 gigawatts of off-peak transmission capacity at three “9”s of reliability. This consumer of transmission capacity may be pulling or pushing energy through this transmission pipe.

Distribution exists as well, with a similar role in the energy ecosystem as transmission but covering smaller capacities and more regional geographies; megawatt and kilowatt capacities spanning cities and neighborhoods with similar service level agreements for reliability.

Centralized generation continues to participate in the ecosystem, utilizing transmission and distribution to deliver product into markets that lack the resources for distributed generation. Yet centralized generation lives right alongside distributed generation, competing for customers on price and quality, each winning business when and where its service and economics are more favorable.

Finally, energy consumers remain in the ecosystem, but their energy bills are decoupled. Line items appear for the kilowatt-hours of off-site energy consumed but also for the distribution and/or transmission infrastructure used along the way for delivery to the service address when consuming as well as when generating and delivering energy offsite, beyond the meter. What’s more, a single service address may have multiple meters provided by different energy companies measuring different businesses in which a single service address is participating. Even more fundamentally, however, all these ecosystem pieces are connected. The grid remains.

Archipelago

Archipelago

On the other hand, what is an energy archipelago? An energy archipelago looks very different from an energy ocean, even though both involve water. Connectedness is gone. Each service address is an island that generates all of its energy needs locally. No transmission or distribution or centralized generation exists and in fact, the grid is no more.

In some regions where there is a dearth of locally available fuels like sunshine, wind or geothermal, there will be alternative fuels. Natural gas and hydrogen delivered via pipeline and used in high-efficiency fuel cells are examples; other examples will emerge to fill this gap as well.

The consumer’s conception of energy changes radically as well. Instead of an ongoing energy service measured in kilowatt-hours, energy morphs into just another appliance like a refrigerator or a furnace. It’s an expensive appliance for sure, so it may be financed when purchased new or rolled into a mortgage when buying an existing home or office, but it comes with a manufacturer’s warranty and will eventually be owned outright.

The service address becomes a dispatch location for maintenance services, just like the appliance provider down the road that services dishwashers and repairs ice makers. In fact your energy storage appliance will have a magnetic sticker on it that unabashedly promotes “Jake’s Energy Appliances” as the last provider to have serviced the appliance, which you call with your smartphone because you have no land-line. Since energy is generated and consumed locally, summertime brownouts and widespread outages caused by hurricanes become stories told to grandchildren as evidence of the much harder life endured by the story teller when they were a child. The grid morphs into thousands of microgrids, then into millions of nanogrids and then the meters disappear altogether, leaving just enough on-site energy generation and storage to meet each site’s demand.

Social Obligation

Energy ocean or archipelago: which eventuality we experience depends on the path taken, of course. The road to an energy ocean is evolutionary. A meaningful number of Investor Owned Utilities (IOU) and municipal utilities make the hard decisions early regarding existing business models. Via their net metering infrastructures they begin providing pricing signals that encourage rather than punish long-term connection to the electrical grid. Distributed generation is rewarded with favorable pricing while utilities carve out revenue from other services involved in maintaining the reliability of the grid and delivering centralized generation into underserved markets with favorable economics. These hard yet critical decisions keep utility companies and the electrical grid relevant long term.

The battle line is drawn at the meter. If utilities are not so proactive and continue to send pricing signals that encourage investment behind the meter, they will be locked out long term. Utilities have no control behind the meter beyond meter-based pricing signals so penalizing distributed generation and storage in order to preserve existing business models necessarily drives innovation behind the meter. Technology and financing creativity flourishes. Meeting residential and commercial energy needs onsite with economical generation and storage becomes commonplace and the grid becomes irrelevant because residential and business owners are forced to take control and hedge against the future risk of skyrocketing energy prices.

Social

Social obligation plays into this story in at least two ways: the stranded utility customers who cannot invest behind their meter are left shouldering an unfair proportion of the utility’s profitability burden while the billions of large financial institution dollars tied up in utility bonds evaporate. Can market dynamics be allowed to dispassionately select the most efficient and economical solutions regardless of the social cost? Probably not.

There will be carnage, just like there was throughout the 30 years following the breakup of the Bell Operating Companies. Many and possibly even most of the utilities we know today will disappear. Large financial institutions will lose hundreds of millions and possibly even billions in capital tied up in stranded utility sector investments. Energy customers who cannot invest behind their meter will suffer much higher energy costs for a time. In the end the societal cost of a complete failure on either of these fronts is too high. Help will be provided. The grid will not disappear entirely. A steady state will be re-achieved that is mostly archipelago, but a fluid ocean like grid will persist in areas where there are fundamental limits to 100% onsite generation and storage. This grid will be funded and managed differently – no PUC but instead, public-private ventures will dominate the financing and ownership structures require for these large societal investments.

So the answer to ocean or archipelago is… yes.

Five Reasons to Embrace LED Street Lighting

The verdict is in: LED street lighting is better! Many cities including San Jose[1] and Oakland[2], CA, Portland[3], OR and others[4] have commissioned independent, third party studies that have all reached the same conclusion – LED street lighting meets or exceeds existing street lighting technologies in terms of the amount and quality of light while simultaneously consuming much less energy.

Here are five reasons why LED is better, the cocktail napkin for LED street lighting:

1. Improved Visibility for Motorists and Pedestrians

Typical nighttime locomotion occurs with lighting in the Mesopic range, so it is important that luminous flux (lumens) and illuminance (lux) values are properly adjusted for the Mesopic range. Huh? Okay, remember those rods and cones you learned about in seventh grade science? They operate best at the wavelengths in the Mesopic range where LED lighting shines (pun intended.)

Mesopic Spectrum

When you move from a brightly lit room in your home to a room with the lights off, it takes several seconds for your eyes to adjust. This adjustment time can be hazardous when piloting a multi-ton vehicle at 35 mph or higher. And yet the High Pressure Sodium (HPS) roadway lighting prevalent today creates just such a situation as you drive from a very bright spot under an HPS light into a dark spot between lights. This poor uniformity, where the difference in brightness between the brightest and dimmest spots is high, causes the human eye to continually and dangerously adjust, with each adjustment taking seconds. A lighting layout with LED lights optimized for human rods and cones and better uniformity – the difference between the brightest and dimmest spots is low – dramatically improves safety.

Roadway Light Layout

To be sure, it is still possible to create a poor layout with LED lighting, which is much more directional. Focusing on very high light levels with large separation between poles, combined with the less diffuse lighting of LED, can create uniformity on par with HPS lighting – which is to say dangerous – so good lighting design is still a prerequisite.

BUGs also play a role here, though not the ones that sacrifice themselves on the altar of your windshield, reducing visibility, or ruining a peaceful nighttime walk with their itchy insurgence. The Illuminating Engineering Society (IES) defines a different kind of BUG, one that stands for Backlight, Up-light and Glare. LED lighting is directional, much more so than other lighting sources like HPS. As a result, it goes where intended. Much less is wasted to backlight, up-light or glare, improving motorist and pedestrian safety.

2. Reduced Energy Consumption

With an LED street lighting system, improved visibility for motorists and pedestrians requires less energy. I know, seems like some fundament law of nature is being violated here, but it’s a true win-win. The wattage needed per LED light to deliver more effective illumination as described above is less than the wattage needed per HPS light today, or other types of lighting as well (e.g., Low Pressure Sodium, Metal Hallide, Mercury Vapor.) Reduced wattage over time means reduced energy consumption and a lower carbon footprint.

Lighting Costs

3. More Accurate Color Representation

Color is an important ingredient when determining what something is from behind the steering wheel, like slippery anti-freeze on the road ahead or a deer just off the shoulder. If natural daylight provides a color representation of 100, HPS lights provide a color representation of about 25 while LED lights are typically over 70, much closer to natural daylight and much easier to identify potential hazards.

Color Side-by-Side

4. Meets the Latest Lighting Standards

Many, perhaps even most, street lighting systems today meet no lighting standards whatsoever or meet lighting standards that are way out of date. While stepping up to an LED street lighting system saves money and improves the quality of light, it’s also the perfect time to come into compliance with the latest standards like ANSI/IESNA’s RP-8-05[1] standard for roadway and adaptive street lighting and the International Commission on Illumination’s CIE-191:2010[2] standard for Mesopic Photometry. Doing so capitalizes on many years of research into the safest and most economical way to provide street lighting.

Lighting Standards

5. Leverages Adaptability

Huge strides have been made these past five years in lighting control technology allowing street lighting system owners to modify light output in response to environmental conditions like surrounding levels of activity levels, local motion, other nearby sources of lighting, etc. This is called adaptive lighting. Adaptive lighting not only reduces energy consumption further through the use of dimming, but also prevents over-lighting, reduces glare and minimizes light pollution. In other words, it helps deliver just the right amount of light when and where it’s needed most.

Adaptability

Home Ownership & Distributed Energy: Two Peas in a Pod

At first blush, home ownership and distributed energy seem about as similar as kale and cheeseburgers. Look a little deeper, though, and a striking similarity emerges, suggesting they may actually be two peas in a pod. That similarity is funding. Where does the money come from for mortgages or distributed energy installations? In the near future, monies for both may come from an identical mechanism.

Ever heard of Fannie Mae or Freddie Mac? If you own a home or have ever worked with or known a mortgage broker, these names may be familiar. Fannie Mae, a friendly nickname for the Federal National Mortgage Association (FNMA), was created in 1938 as part of FDR’s New Deal. The goal was home ownership, and it worked! By creating a secondary market for mortgages, funds became available for home loans – lots of home loans.

But what does that mean – secondary market? In the old days, your neighborhood bank provided passbook savings accounts. They paid you interest in return for holding your money. To pay that interest they put your money to work. By pooling your money and all your neighbors’ monies together, they could do things like make loans. As long as the interest they received on loans exceeded what they were paying on savings accounts they made money. However, they could only loan the money they collected from you and your neighbors. This was very limiting. Few people owned their own homes as a result. Enter Fannie Mae and the secondary market.

Nobody Wants To Be Second

Fannie Mae was established to provide local banks with federal money to finance home mortgages. They accomplished this by creating a secondary market, which sells mortgage-backed securities (MBS) to investors. An MBS is a pool of loans with similar characteristics. An investor buys, or invests in, an MBS because it provides a fixed return over a period of time. This process is called securitization. More importantly, this process expanded the amount of money to lend well beyond what any neighborhood could support. Today investors all over the world invest in US mortgage-backed securities in droves. Over time the primary market, your neighborhood bank, has given way to the scale and efficiency of this secondary market.

Secondary Market

In 1970, Freddie Mac was created to perform the same function as Fannie Mae and provide competition to the deemed monopoly Fannie Mae had become. Like Fannie Mae, Freddie Mac is a friendly nickname for the Federal Home Loan Mortgage Corporation (FHLMC). Together Fannie Mae and Freddie Mac, both government-sponsored enterprises (GSE), have made pervasive home ownership a reality, even for people with poor credit.  But don’t get me started on the sub-prime debacle of the previous decade…

Put the “Fun” in Funding

How is this related to energy? Today if you want to put solar on your rooftop or a wind generator on your property you must pay for the system with money you have saved, or possibly a home equity loan from your local bank, after you fight with your homeowner’s association of course. It’s happening, but locally, and in ones and twos. Widespread adoption of distributed renewable energy is not occurring, even though the economics make tons of sense in many regions today. Like the limitations neighborhood banks placed on home ownership, access to funding is inhibiting widespread adoption. Can securitization of energy help?

Rooftop Solar

It can. And it’s starting. SolarCity Corporation is the poster child for the securitization of energy. A SolarCity customer signs a twenty year agreement for energy services. In return they receive an additional energy bill from SolarCity. Nothing gets paid up front. The combination of their old utility energy bill and their new SolarCity energy bill is generally about 30 percent less than they paid before because a meaningful percentage of their energy needs are met by the sun. The rooftop equipment delivering this solar energy is essentially leased and rolled into the customer’s monthly payment. SolarCity owns the equipment and operates it on the customer’s behalf. But where does SolarCity get the funding to pay for the equipment in the first place? Well, they have a fund. An investor buys, or invests in, the SolarCity fund because it provides a fixed return over a long period. It’s not a mortgage-backed security, but it plays one on TV. Plus, because of the solar Investment Tax Credit (ITC) the fund provides unique benefits to investors with a tax equity appetite. In turn, SolarCity uses this money to pay for the upfront cost of the solar equipment needed to deliver the energy. Returns to the investor are paid from monthly energy payments by customers. Like a mortgage-backed security, the fund aggregates large numbers of rooftop solar installations and customer payments, improving the economics and mitigating risk in the same way a diversified portfolio mitigates risk.

Government Sponsored or Star Trek Enterprise?

SolarCity is a private sector company, although it recently IPO’ed so it is publicly traded as SCTY. It is not, however, a government-sponsored enterprise like Fannie or Freddie, even though it shares many characteristics of a GSE. What would happen if a GSE or two were created as part of a New New Deal, with a goal of widespread distributed energy generation via energy-backed securities and a nickname of Felix? Well then, home ownership and distributed energy would indeed be pod-mates.

Grid, Grid Everywhere, But Not An Erg To Drink

Everywhere you read it’s energy grid this, electrical grid that. The grid is getting smart, and clean. The grid can store energy. Two-way communications throughout the grid is commonplace, as are renewable energy sources. Microgrids are improving grid reliability and the overall grid architecture is becoming more and more distributed.

Yet looking out my window, nothing appears any different. Is my grid smarter or communicating or more distributed? Are today’s ergs somehow richer or more glamorous?

Distributed Is the New Black

No. Well, not yet anyway. But change is afoot! In the beginning there was the electrical grid, a truly dizzying feat of real-time engineering. Hit brew on your coffee machine and viola, it turns on. 120 volts at 60 hertz (in the U.S.) delivered to your doorstep from a dam or coal-fired power plant or nuclear power plant hundreds or even thousands of miles away. It’s magic!

Then there was the microgrid. A microgrid is a localized grouping of electricity sources and loads that normally operate connected to and synchronous with the traditional centralized grid, but can disconnect and function autonomously as physical and/or economic conditions dictate.[1] The scale of a microgrid is smaller than a traditional, centralized energy source like a coal-fired power plant. A microgrid might generate 1 to 10 megawatts into a 20 kilovolt distribution system, as opposed to 667 megawatts for an average coal-fired power plant into a 110 kilovolt transmission system on the centralized grid. Of course the service territory for a microgrid is smaller too, so its capacity can be smaller, matching a smaller demand.

Nanogrid Figure 2

And now we have the nanogrid. A nanogrid is an autonomous, self-contained grouping of electricity sources and loads that need not be connected to the traditional centralized grid, or microgrid, yet can be aggregated together and connected to the grid when the economic value of its available energy overcomes the infrastructure cost of the connection. As its name implies, we have moved the decimal on scale to the left a few more places. Nanogrid electrical sources are smaller still, from a few watts up to many hundreds of watts. More fundamentally, nanogrids are autonomous. They need no grid in the traditional sense, nor any of the costly infrastructures required to be grid-connected. They are able to generate their own energy, enough energy to perform their function, plus more in many cases. Examples include personal kinetic chargers like the nPower PEG product that can charge mobile devices, street side trash compactors like the BigBelly that use solar energy to compact garbage, solar-powered transportation fleets like eNOW Energy Solutions that generate and store enough energy to control the environment inside a trailer during transport, and outdoor lighting like Inovus Solar-Enhanced Lighting that captures solar energy during the day and uses it to provide lighting at night. Electric and hybrid vehicles may also qualify as nanogrids to the extent their batteries have available charge.

Connections Are the Key

Energy is becoming more and more distributed, even mobile in some cases, and autonomous. Yet being connected remains fundamental, whether grid-connected, control-connected or both. Being grid-connected allows a nanogrid to operate as just another electricity source on the grid, or redundantly alongside the grid, but the connection requires costly infrastructure. This type of connection is electrical. Control-connected is different. This type of connection involves two-way communications. Electricity sources and loads in a nanogrid communicate, coordinating behavior to insure autonomy. For example, a solar light directs its solar energy to one or more loads while the sun is shining, and may also top off the batteries when low. Then when the moon is shining, its behavior changes to run the loads off the batteries. So a nanogrid doesn’t need to be grid-connect, but it may be, and it is always control-connected.

Nanogrid Figure 3

Together We Stand

A single, autonomous nanogrid has at most a relatively small amount of energy at the ready. However, nanogrids can be aggregated. When the economics are favorable, large numbers of grid-connected and control-connected nanogrids can be summoned to wield large and meaningful amounts of energy. For example, all the electric vehicles within a county that are plugged in and have more than 10 extra kilowatt-hours of stored energy onboard can be selected and then targeted to deliver their energy to the grid during a 15 minute window in the afternoon while the natural gas peaker plant spins up.

Nanogrid Figure 4

A centralized aggregation point with detailed, near real-time information about these nanogrids is required for this example to be realized, but these can be high value uses for the highly distributed energy in nanogrids that warrant the economics of being connected.

Distributed Ergs

Outside your window things may not look any different today, but they will. It’s inevitable. The electrical grid must evolve. Energy generation is moving to the edge – to the county and city and neighborhood and commercial building and residential house – closer to the consumer. Your ergs may not be richer or more glamorous, but they will be less haggard from their travels.
